Description

Self-Contained Boat Network – Complete Network f\\/8 Devices w\\/Internal Terminators \\u0026amp; Power FeedInstalling small NMEA 2000® networks is quicker and easier than it’s ever been with the Self-contained Boat Network (SBN) from Actisense.The equivalent of eight T-pieces in a single case provides a significant time and space saving with no more connecting multiple T-pieces together. Termination resistors are built in which increases the saving on time and space.Once the attached 3 meter cable is connected to the boats power supply, an NMEA 2000 network for up to eight devices is ready to use, taking ‘plug \\u0026amp; play’ to the next level.Features:Self-contained NMEA 2000 NetworkIntegrated Termination Resistors8x NMEA 2000 dropsRuggedized, flame retardant over-molded housingMetal coupling nutsIntegrated EMI ShieldOrange, UL Rated, 3-meter power cableColor coded wires, stripped and tinnedLow cost, quick to install, and provides an easy way to connect multiple NMEA 2000 devicesSimple installation, fewer components, more reliable, lower costAccommodates the vast majority of compact NMEA 2000 networksSuitable for wet and harsh conditions- highly desirable in marine environmentsReliable, long lasting connectionsLess likely to be susceptible to interferenceUL rated cable provide peace of mind. Color easily differentiates the power cable form drop cablesQuick installation, no special tools requiredTechnical Specifications:ElectricalRated Current – 3ARated Voltage – 60 V (AC\\/DC)Internal Termination Resistors – 2 x 120Ω 250mWMechanicalFemale Contact – Phosphor bronze, gold platedContact Carrier – PA66 (30% Glass filled), blackContact Polarization – Standard M12 – “A” – polarizationMating Thread – M12Screw Cap – Brass, nickel platedO-Ring Seal – Rubber, blackHousing – TPU (Halogen Free) over Epoxy filled PBT housingFlammability rating – UL94 V-0Internal Housing Shield – Copper foilCable Jacket Material – 0.8mm Nom. PVC, orangeCable Outer Diameter – 6.8mmCable Length – 3mWire Length – 150mm (10mm stripped and tinned)Wire Jacket – PVC, Red \\u0026amp; BlackWires – 16 AWG (stripped and tinned)Drain – 18 AWG (34 strand tinned copper)Cable Shield – Al-mylarWeight – 410gApprovals and CertificationsProtection – IP67 (when mated)Operating Temperature – -25°C to +70°CStorage Temperature – -40°C to +85°CThis product may not be returned to the original point of purchase.Please contact the manufacturer directly with any issues or concerns. Specifications:Data Interface: NMEA 2000Cable Length (Feet): 9.8’Box Dimensions: 1\\
